Private Network
SMB / Industry

WS5G2/7G2/10G2

  • Centralized forwarding and local forwarding

  • Wired & Wireless integration

  • Multimedia

  • Security

  • Simple & reliable network

  • QoS

Description

The Z-COM WS5/7/10G2 series is a wireless LAN controller (WLC) with centralized network management developed for Small and Medium Business (SMBs). It brings together Z-COM intelligent software and RF excellence to create a best wireless experience for your growing organization.






Designed for fast, easy-to-use and intelligent platform, WS5/7/10G2 series is ready for enterprise to manage access points as a total solution to strengthen your business operations and investment protection.



負載平衡(Load-Balance)-手機圖-測試別的文字(800px) (1).gif無縫漫遊2024-01-12(元件打散製圖層-iloveimg網頁壓縮).gif

Load Balance

Fast Roaming



Perfect for businesses who are eager to wireless service such as video streaming, secure access control, flexible deployments, and future IoT, ideal for communities, campus, factories, and hospital, etc.


The WS5/7/10G2 series opens a completely new paradigm in network configuration, operation, and monitoring through network optimization.


Integrates wired and wireless platform

Wired & Wireless Integration

Integrates wired and wireless platform, giving resilient and wide coverage.



IP-CAMs_ video streaming

Multimedia

Simultaneously connects IP-CAMs, giving high quality of video streaming.


Security

Security

Designed for centralized authentication and authorization to eliminate the requirements to configure and update

individual devices.


seamless upgrades.


Simple & Reliable Network

Deploys centralized management system via easy-to-setup and seamless upgrades.

Quality of Service

Quality of Service

Prioritizes certain data flows in a network over others for efficient operation.


Simplifies device management


User-friendly GUI

Simplifies device management and monitoring with an intuitive dashboard interface design.


創建 2.4GHz or 5GHz 的 Wireless模板.png

Create 2.4GHz or 5GHz's Wireless Profile.

Centralized management platform to optimize performance and efficiency.


建立 Group.png

AP Grouping


確認無線設備 (TAP) 已加入 Group 中,並套用所設定的模板.png

TAP is in AP Group, and apply the Wireless Profile.


Success Stories:



Series Products:




WS5G2

WS7G2

WS10G2

CPU

Model

Intel

Intel

Intel

Quantity

1

1

1

Memory


DDR3L 8GB

DDR4 16GB

DDR4 32GB

Management Ports

1GbE RJ45

4

6

6

10GbE SFP+

-

2

4

40GbE QSFP

-

-

-

Storage


SSD 64G

SSD 64G

SSD 64G

Chassis


1U

1U

1U

L2 Switch Capability


Yes

Yes

Yes

Power Supply


12V/5A DC Adaptor

12V/5A DC Adaptor

12V/7A DC Adaptor

AP Capacity

128

256

512


Specification

HARDWARE

Power WS5G2: 12V/5A DC Adapter
WS7G2: 12V/5A DC Adapter
WS10G2: 12V/7A DC Adapter
Dimensions (L) x (W) x (H) mm WS5G2: 232 x 152 x 44
WS7G2: 231 x 197 x 44
WS10G2: 231 x 197 x 44
Weight WS5G2: 2.7 Kg
WS7G2: 2.7 Kg
WS10G2: 2.7 Kg
Interfaces WS5G2:
4 × RJ45

WS7G2:
6 × RJ45
2 x SFP+

WS10G2:
6 × RJ45
4 x SFP+
Environmental Conditions Operating Temperature: 0°C ~ +40°C
Operating Humidity: 10% ~ 95% (non-condensing)

NETWORK ARCHITECTURE

IP IPv4, IPv6
VLAN Supported
Redundancy 1+1 Backup Supported
DHCP Server Supported
Fast Roaming Supported
RF Management 5G Priority
Auto TX Power Control
Auto Channel Selection
Routing Static
Dynamic

APPLICATIONS

Mesh Coverage Supported
WDS Supported

CERTIFICATIONS

IEC/EN 60950
EN55032 & EN55024
WEEE & RoHS
EN 61000-3-2
EN 61000-3-3

SECURITY

Standards 802.11x, WPA, WPA2, WPA3
Access Control Access Time Schedule
MAC ACL
UE Authentication & Accounting Supported
User Isolation Supported
Rogue AP Detection Supported
IGMP Snooping Supported
DHCP snooping Supported
DoS attack prevention CLI
WEB UI
GUI
SNMP
Packets Limitation Supported

CAPACITY

Managed APs WS5G2: 128 (Thin APs)
WS7G2: 256 (Thin APs)
WS10G2: 512 (Thin APs)
UE Data Traffic WS5G2: 2Gbps
WS7G2: 5Gbps
WS10G2: 10Gbps
MAC Address Table WS5G2: 8K
WS7G2: 16K
WS10G2: 30K

MULTIMEDIA & QoS

802.11e/WMM Supported
Load Balance Between APs Based on Numbers of UEs
Between APs Based on Traffic
Bandwidth Control User Specific
VLAN Users
MAC Users
Radius Users

SUPPORTED WIRELESS STANDARDS

802.11a
802.11b
802.11g
802.11n
802.11ac
802.11ax
802.11r
802.11k
802.11v
802.11d
802.11e
